NEW! Mini Monitor by Point Source Audio
PSA Model# SPOT-01N
The SPOT-01N Mini Monitor is an extremely compact, passive loudspeaker able to provide coverage where space is limited. Measuring a mere 4", this 16-ohm speaker has a power handling of 100W which can provide the gap coverage to amplify speech or sound in practically any venue.
SPOT-01N delivers as its name implies!
The versatility for fill and spot coverage is endless for including front/side fill, over/under balconies, and spot monitoring.
Many Configurations
Specifications
Transducer: One 4" Cone Driver
Impedance: 16 Ohms
Power Handling: 100w RMS, per EIA RS-426-A
Sensitivity: 1w1m 86 dB, Measured with Pink Noise in Half Space
Frequency Response: 145 Hz to 11k Hz ±3 dB, -10 at 105 Hz
Max Continuous SPL: 106 dB
Max Peak SPL: 112 dB
Dynamic Range: 100 dB
Phase Response: 200 Hz to 12 kHz ±45˚
Coverage: 90˚ Horizontal and Vertical
Weight: 3.6 lbs (1.6 kg)
Dimensions: 4.75” x 4.25” x 4.25” DxWxH (120mm x 108mm x 108mm) Depth Includes Rear Connector
Accessory: Mounting Bracket (Sold Separately)
